Indoor Simplex Fiber Patch Cables With Fanout Length Of 350mm Or Customized
Product Details:
| Place of Origin: | China |
| Brand Name: | SkyOptics / OEM / ODM |
| Certification: | CE / RoHS / FCC |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 unit |
|---|---|
| Price: | US$1~US$4999 |
| Packaging Details: | Plastic Tray/Plastic Bag/Customized |
| Delivery Time: | Same day delivery~one week |
| Payment Terms: | T/T / L/C / Paypal / Westerm Union |
| Supply Ability: | 100kpcs/month |
|
Detail Information |
|||
| Cable Diameter: | 0.9mm/2.0mm/3.0mm | Product: | Fiber Loopback Cable |
|---|---|---|---|
| Fiber Grade: | G.652D/G.657A1/G.657A2 | Connector: | LC & MTRJ |
| Connector Type: | LC/SC/FC/ST/MPO/MTP | Cable Strand: | 1, 2,4, 6, 8, 12 Cores |
| Polishing Type: | PC/UPC/APC | Fanout Length: | 350mm Or Customized |
| Highlight: | Simplex Fiber Patch Cables,Indoor Fiber Patch Cables,Simplex Patch Cord Customized |
||
Product Description
Simplex Indoor Fiber Cable Fiber Patch Cable With Fanout Length Of 350mm Or Customized
Product Description:
We offer various Connector Types to choose from, including LC, SC, FC, ST, MPO, and MTP. Our LC UPC to LC UPC Connector Type is the most popular choice, providing a secure and reliable connection. Our LC UPC Duplex Patch Cable is specifically designed for duplex fiber jumper applications.
The Jacket Material of our Fiber Patch Cables is available in three options, PVC, LSZH, and OFNP. Our PVC Jacket Material is known for its durability and flexibility, while LSZH is perfect for applications where low smoke and zero halogen emissions are crucial. OFNP is ideal for plenum spaces, meeting strict fire safety requirements.
Our Fiber Patch Cables are available in Singlemode and Multimode Cable Types, giving you the flexibility to choose the best option for your network. We also offer Cable Strands in 1, 2, 4, 6, 8, and 12 Cores, providing the perfect selection for your specific networking needs.
Our Fiber Patch Cables are ideal for use in a variety of applications, including data centers, telecommunications, and LAN/WAN connections. They are easy to install and maintain, ensuring that your network is running smoothly.
Order now and experience the high-quality performance of our Fiber Patch Cables. Choose the perfect combination of Fiber Mode, Connector Type, Jacket Material, Cable Type, and Cable Strand to meet your networking requirements. Our Fiber Patch Cables are the perfect solution for your networking needs, providing reliable and fast data transmission.
Features:
- Product Name: Fiber Patch Cables
- Cable: Simplex Indoor Fiber Cable
- Connector Type: LC/SC/FC/ST/MPO/MTP
- Cable Length: 1m/ 2m/ 3m/ 5m/ 10m/ 15m/ 20m/ 30m/ 50m/ 100m
- Jacket Material: PVC/LSZH/OFNP
- Polishing Type: PC/UPC/APC
- LC UPC to LC UPC
- LC UPC to SC UPC
- LC UPC to FC UPC
Technical Parameters:
| Technical Parameters | Description |
|---|---|
| Product | Fiber Patch Cable |
| Cable Type | Singlemode/Multimode |
| Fiber Mode | Single Mode 9/125, OS2 |
| Cable Strand | 1, 2, 4, 6, 8, 12 Cores |
| Polishing Type | PC/UPC/APC |
| Application | Telecommunication/Local Area Network/Data Center |
| Mode | Multimode |
| Fiber Grade | G.652D/G.657A1/G.657A2 |
| Cable | Simplex Indoor Fiber Cable |
| Fanout Length | 350mm Or Customized |
| Description | LC UPC Duplex Patch Cable, Duplex Fiber jumper |
Applications:
The Fiber Patch Cables are ideal for various fiber applications, including data centers, local area networks (LANs), wide area networks (WANs), and telecommunications. They are perfect for connecting devices such as switches, routers, servers, and storage area networks (SANs).
The LC UPC Duplex Patch Cable is a popular option for fiber optic connections. It features a small form-factor duplex connector with a latch mechanism that ensures secure connectivity. This cable is compatible with LC and MTRJ connectors and is available in customized fanout lengths of up to 350mm.
The Fiber Patch Cables are available in three jacket materials: PVC, LSZH, and OFNP. PVC is a cost-effective option that is ideal for indoor use, while LSZH is a low-smoke, zero-halogen material that is suitable for use in poorly ventilated areas. OFNP is a flame-retardant material that is suitable for plenum spaces.
The Fiber Patch Cables are available in three polishing types: PC, UPC, and APC. PC (Physical Contact) is the standard polishing type and is suitable for most applications. UPC (Ultra Physical Contact) is a higher-grade polishing type that provides better performance. APC (Angled Physical Contact) is the highest-grade polishing type and is ideal for applications that require low back reflection.
The Fiber Patch Cables are available in single-mode 9/125 fiber mode (OS2). This fiber mode is suitable for longer distances and higher bandwidths. The LC UPC Duplex Patch Cable is a popular choice for single-mode fiber optic connections.
In summary, the Fiber Patch Cables from Sky Optics are a reliable and high-quality option for various fiber applications. The LC UPC Duplex Patch Cable is a popular option that features a small form-factor duplex connector with a latch mechanism that ensures secure connectivity. With customized fanout lengths of up to 350mm and three jacket materials and polishing types to choose from, these cables are suitable for a wide range of applications.
