25Gbps SFP28 40km SMF Transceiver, LC, 0~70°C, with DDM
Product Details:
| Place of Origin: | China |
| Brand Name: | SkyOptics / OEM / ODM |
| Certification: | CE / FCC / RoHs |
| Model Number: | SPP-Cxx25-40x |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 unit |
|---|---|
| Price: | US$1~US$4999 |
| Packaging Details: | Plastic Tray/Plastic Bag/Customized |
| Delivery Time: | Same Day Delivery~one Week |
| Payment Terms: | ,L/C,T/T,Western Union |
| Supply Ability: | 100kpcs/month |
|
Detail Information |
|||
| Max Data Rate: | 25.78Gbps | Wavelength Range: | 1270–1310 Nm |
|---|---|---|---|
| Center Wavelength: | 1271nm / 1291nm / 1311nm | Extinction Ratio: | ≥ 3.5 DB |
| Receiver Sensitivity: | -18 DBm | Hot Swappable: | Yes |
| LOS Hysteresis: | 0.5 DB | Diagnostic Accuracy: | ±3 DB (Power), ±3°C (Temp) |
| Data Rate: | 25.78Gbps | Side-Mode Suppression Ratio: | ≥ 30 DB |
| Storage Temperature: | -40°C To +85°C | ||
Product Description
Product Description
Engineered for reliability and performance, the SPP-Cxx25-40x supports 25G data transmission over 40km of single-mode fiber. It combines a high-power DFB laser and a sensitive APD receiver, offering excellent optical performance and diagnostic capabilities for network administrators.
Features
Hot-pluggable SFP+ design
Internal CDR support for signal integrity
Digital diagnostics via I2C interface
Low dispersion and high sensitivity
LC duplex connector
Power consumption < 1.32W
Technical Parameters
Max Data Rate: 25.78Gbps
Transmit Power: +0 to +6 dBm
Receiver Sensitivity: -18 dBm
Wavelength Range: 1270–1310 nm
Extinction Ratio: Min 3.5 dB
LOS Hysteresis: 0.5 dB
Operating Humidity: 5% to 85%
Storage Temperature: -40°C to +85°C
Diagnostic Accuracy: ±3 dB (Power), ±3°C (Temp)
Applications
25GBASE-ER applications
Fiber optic backbone networks
Data center extensions
Metropolitan area network (MAN) links
