100G QSFP28 DWDM Transceiver 40km 6W Power O-Band
Product Details:
| Place of Origin: | China |
| Brand Name: | SkyOptics / OEM / ODM |
| Certification: | CE / FCC / RoHs |
| Model Number: | SQ-100G-OD40-XXX5S |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 unit |
|---|---|
| Price: | US$1~US$4999 |
| Packaging Details: | Plastic Tray/Plastic Bag/Customized |
| Delivery Time: | Same Day Delivery~one Week |
| Payment Terms: | ,L/C,T/T,Western Union |
| Supply Ability: | 100kpcs/month |
|
Detail Information |
|||
| Transmission Distance: | 40km | Power Dissipation: | < 6W |
|---|---|---|---|
| Form Factor: | QSFP28 | Diagnostic Interface: | I²C With DDM |
| Tx Power: | 2 To 7.1 DBm | Data Rate: | 100Gbps (4x25Gbps NRZ To PAM4) |
| Rx Sensitivity: | ≤ -16.5 DBm | Modulation Format: | PAM4 |
| Hot Pluggable: | Yes | Power Supply: | 3.3V |
| Hot Swappable: | Yes | Connector Type: | LC Duplex |
| LOS Assert: | -26 DBm | ||
| Highlight: | 100G QSFP28 DWDM transceiver 40km,low power QSFP28 optical module O-Band,100G transceiver with 0-70°C operation |
||
Product Description
Product Description
This energy-efficient 100G QSFP28 transceiver is designed for demanding network environments. It operates in the O-Band DWDM spectrum and supports up to 40km reach with best-in-class power efficiency (<6W). Its robust design ensures stable performance across a wide temperature range (0°C to 70°C), making it ideal for both data centers and outdoor applications.
Features
Power dissipation < 6W
Wide operating temperature: 0°C to 70°C
O-Band DWDM with 200GHz spacing
Integrated PFEC for enhanced error correction
Compliant with IEEE 802.3cd and CAUI-4
Digital diagnostics via I²C interface
LC duplex connector for easy integration
RoHS and safety certified
Technical Parameters
| Parameter | Details |
| Supply Voltage | 3.3V |
| Power Consumption | < 6W |
| Case Temperature: |
0°C to 70°C |
| Wavelength |
1304.58–1312.58nm |
|
Tx Output Power |
2 – 7.1 dBm |
| Rx Sensitivity | ≤ -16.5 dBm |
| LOS Assert | -26 dBm |
| Rx Sensitivity: | -16.5 dBm |
| Channel Spacing | 200GHz |
| Link Budget | > 18.5 dB |
| Data Rate | 100Gbps (PAM4) |
| Distance | 40km over SMF |
| Connector | LC Duplex |
Applications
Cloud data center interconnects
5G fronthaul and midhaul networks
High-speed enterprise networks
Network function virtualization (NFV) platforms
