High-Speed 800G Transceiver for Flexible Networking
Product Details:
| Brand Name: | SkyOptics / OEM / ODM |
| Certification: | CE / RoHS / FCC |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Unit |
|---|---|
| Price: | US$1~US$4999 |
| Packaging Details: | Plastic Tray/Plastic Bag/Customized |
| Delivery Time: | Same Day Delivery~one Week |
| Payment Terms: | T/T / L/C / Paypal / Westerm Union |
| Supply Ability: | 100kpcs/month |
|
Detail Information |
|||
| Wavelength: | 1550nm | Transmitter Type: | VCSEL |
|---|---|---|---|
| Tx Power: | -4.6-4dBm | Rx Sensitivity: | -4.6dBm |
| Receiver: | PIN And TIA Array On The Receiver Side | Case Temperature Range: | 15°C To 70°C |
| Power Consumption: | Less Than 10W | Compatibility: | Multi-vendor |
| Highlight: | 800G transceiver for high-speed networking,800G optical module with flexible connectivity,high-performance 800G transceiver for data centers |
||
Product Description
Product Description
The QSFP-DD800 2xLR4 Optical Module is an advanced 800 Gigabit transceiver designed for the high-speed demands of modern data centers.
This versatile module supports multiple configurations, including 1x800GbE, 2x400GbE, 4x200GbE, and 8x100GbE, providing a flexible and scalable solution for any network architecture.
Features
Product Name: 800G Optical Module
Rx Sensitivity: -4.6dBm
Form Factor: QSFP-DD
Power Consumption: Less Than 10W
Application: 1x800GbE / 2x400GbE / 4x200GbE / 8x100GbE
Wavelength: 1550nm
Technical Parameters
|
Parameter |
Details |
|
Power Consumption |
Less Than 10W |
|
Tx Power |
-4.6 to 4dBm |
|
Transmitter Type |
VCSEL |
|
Rx Sensitivity |
-4.6dBm |
|
Compatibility |
Multi-vendor |
|
Connector |
Dual MPO-12 Connector |
|
Form Factor |
QSFP-DD |
|
Receiver |
PIN and TIA Array |
|
Wavelength |
1550nm |
|
Temperature Range |
15°C to 70°C |
Applications
The SkyOptics 800G Fiber Optic Module is a high-quality, versatile product for a wide range of networking needs. Manufactured in China, it holds CE, RoHS, and FCC certifications, ensuring compliance with international standards.
With a minimum order quantity of just 1 unit and a flexible delivery time from same-day to one week, it is an accessible and reliable choice for projects of any size. We offer a supply ability of 100k units/month and flexible payment options including T/T, L/C, PayPal, and Western Union.
